Description
Value

CEA-2006 Compliant
Number of Channels 2
Rated Power
continuous power 50 Watts RMS x 2 @ 4-Ohms
75 Watts RMS x 2 @ 2-Ohms
150 Watts RMS x 1 @ 4-Ohms Bridged/Mono
Total Power
total sum of 'rated power' 150 Watts
Dynamic Power
powercube measurement (info) 57 Watts x 2 @ 4-Ohms 0° Res
85 Watts x 2 @ 2-Ohms 0° Res
Bridgeable Yes
Efficiency (average) 60% @ 4-Ohm
54% @ 2-Ohm
Crossover Controls High-Pass (HP): 80Hz @ 12dB/octave Butterworth
Low-Pass (LP): 50Hz-250Hz @ 12dB/octave Butterworth
Tone Controls Punch Bass: 0dB to +12dB @ 45Hz
Signal Input Low Level: 1 RCA pair
Signal Output Low Level: 1 RCA pair
Power Input Connector Screw terminal barrier strip
Power Wire Gauge 4 AWG
Speaker Output Connector Screw terminal barrier strip
Speaker Wire Gauge 8 AWG
Heat Sink Type Extruded Aluminum
Cooling Convection
Remote Controls n/a
Visual Indicators Power
Protect
Circuit Topology Class Class A/B
Frequency Response 20Hz to 20kHz +/-1dB
Shipping Weight TBA Lbs.
(TBA Kg.)
Dimensions (HxWxL) 2.40 x 7.67 x 11.54 (in)
6.10 x 19.49 x 29.30 (cm)
