Description                                Value

CEA-2006 Compliant


Number of Channels 2
Rated Power
continuous power 100W x 2 @ 4-Ohms RMS
200W x 2 @ 2-Ohms RMS
400W x 1 @ 4-Ohms bridged RMS
Total Power
total sum of 'rated power' 400 Watts
Dynamic Power
powercube measurement (info) 140 Watts x 2 @ 4-Ohms 0° Res
334 Watts x 2 @ 2-Ohms 0° Res
Bridgeable Yes
Efficiency (average) 70% @ 4-Ohm
65% @ 2-Ohm
Crossover Controls High-Pass (HP): 50Hz-500Hz 12dB/octave Butterworth
Low-Pass (LP): 50-500Hz 12dB/octave Butterworth
Tone Controls Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or
Punch EQ2 Treble: 0dB to +12dB @ 12kHz
Function depends upon LP/AP/HP switch position
Signal Input Low level: 1 RCA pair
Signal Output Low level: 1 RCA pair
Power Input Connector Block
Power Wire Gauge 4 AWG
Speaker Output Connector Screw terminal barrier strip
Speaker Wire Gauge 8 AWG to 18 AWG
Heat Sink Type Cast aluminum
Cooling Convection
Remote Controls Optional PEQ Remote Punch EQ
(overrides built-in Punch EQ2)
Visual Indicators Power
Thermal
Protect
Circuit Topology Class Class A/B
Frequency Response 20Hz to 20kHz +/- 1.0dB
Shipping Weight 7.25 Lbs.
(3.28 Kg.)
Dimensions (HxWxL) 2.25 x 7.625 x 10.25 (in)
5.71 x 19.37 x 26.03 (cm)

Dimensional Diagram
