Description Value

CEA-2006 Compliant
Number of Channels 2
Rated Power
continuous power 120W x 2 @ 4-Ohms RMS
200W x 2 @ 2-Ohms RMS
400W x 1 @ 4-Ohms bridged RMS
2-Ohms x 1 bridged Stable
Total Power
total sum of 'rated power' 400 Watts
Dynamic Power
powercube measurement (info) 145 Watts x 2 @ 4-Ohms 0° Res
243 Watts x 2 @ 2-Ohms 0° Res
Bridgeable Yes
Efficiency (average) 76% @ 4-Ohm
71% @ 2-Ohm
Crossover Controls High-Pass (HP): 50-500Hz 24dB/octave Butterworth
Low-Pass (LP): 50-500Hz 24dB/octave Butterworth
Tone Controls Treble: 0dB to +12dB @ 12kHz
Bass: 0dB to +18dB @ 45Hz
Signal Input Low level: 1 RCA pair
Signal Output Low level: 1 RCA pair
Power Input Connector Block
Power Wire Gauge 4 AWG
Speaker Output Connector Screw terminal barrier strip
Speaker Wire Gauge 8 AWG to 18 AWG
Heat Sink Type Cast aluminum
Cooling Convection
Remote Controls Optional Remote Punch EQ
(overrides built-in Punch EQ)
Visual Indicators Power
Thermal
Protect
Circuit Topology Class Class A/B
Frequency Response 20Hz to 20kHz +/- 1dB
Shipping Weight 10.29 Lbs.
(4.66 Kg.)
Dimensions (HxWxL) 2.14 x 8.14 x 11.41 (in)
5.42 x 20.68 x 28.97 (cm)
Dimensional Diagram
