Description
Value

CEA-2006 Compliant
Number of Channels 5
Rated Power
(RMS Continuous Power) 50 Watts x 4 + 200 Watts x 1 @ 4-Ohms
75 Watts x 4 + 300 Watts x 1 @ 2-Ohms
Total Power
(Sum of Rated Power) 600 Watts
Dynamic Power
(PVC/PowerCube® Measurement)
Bridgeable Yes
Efficiency (average)
Crossover Controls Channels 1/2/3/4:High-Pass 80Hz
Channels 1/2/3/4:Low-Pass variable 50Hz - 250Hz
Sub Channel:Low-Pass variable 40Hz - 130Hz
Tone Controls Channel 1/2/3/4:0dB/+6dB/+12dB @ 45Hz
Sub Channel:Variable 0dB to +12dB @ 45Hz
Sub Channel:0°/180° Phase Control
Signal Input Low Level:3 Pair RCA
Signal Output n/a
Power Input Connector Screw Terminal
Power Wire Gauge 4 AWG
Speaker Output Connector Screw Terminal
Speaker Wire Gauge 8 AWG
Heat Sink Type Extruded
Cooling Convection
Remote Controls Remote Punch Level Control
Visual Indicators Power
Protect
Circuit Topology Class Class A/B
Frequency Response 20Hz - 20kHz +/-1dB
Shipping Weight
Dimensions (HxWxL) 2.40" x 7.67" x 17.09"
(6.10cm x 19.49cm x 43.40cm)
Dimensional Diagram
